Fields of application：

metal powder, non-metal powder, pharmaceutical, chemical, new energy, new materials, scientific research and teaching and other fields。

Complies with：

1. EP 7.0 2.9.34 tapped density of powders;

2. USP32-NF27<616> TAPPED DENSITY OF POWDERS

Features:

1. 4.3-inch touch screen, provides a more convenient, simple and natural way of human-computer interaction;

2. uses a long-life, high-reliability motor component with excellent start-stop response capability;

3. uses a 32-bit embedded RISC microprocessor with low cost, high performance, and low power consumption;

4. For the application scenarios of test instruments, a customized embedded operating system is used to make the system have stronger stability and software expansion capabilities;

5. A lightweight, resource-intensive, high-performance, highly reliable, configurable and beautiful GUI (human-computer interface) is used to improve the user experience;

6. Built-in micro receipt printer;

7. The measurement results are accurate to 3 decimal places;

8. Excellent network connectivity, which can support remote software upgrades and customization needs;

9. supports the generation and download of electronic reports, and supports Excel and PDF formats.

Supported test station(s)：

one、two、three

Tapped frequency：

0 ~ 300 rotations/minute

Tapping method：

Rotation during tapping down

Drop height：

3mm, 14mm

Voltage：

110/220V 50/60Hz

Graduated cylinder volume：

250mL

Repeatability error:

≤ 1%

Built-in printer:

1. paper width：58 mm
2. Paper warehouse：≤ 30 mm
3. Roll length：9.42 m
4. printing speed：60 mm/s
